產地	河北
產品認證	ISO2001
電池容量	1001mAh-2000mAh
規格	85*35*25
類型	新款移動電源
適用范圍	中小型車輛啟動
適用類型	后備電源
輸入電壓	220.330
顏色	綠
品牌	孫大燈
加工定制	是
電源容量	1500毫安
是否支持太陽能	是
電芯類型	液態鋰離子電芯(18650)
LED等照明	是

產品簡介

啟動電源是汽車維修行業必備工具，具有電池充電，車輛啟動，焊接等功能。尤其在北方地區冬季使用，會在很大程度上減輕蓄電池的負擔，延長蓄電池的使用壽命，給消費者帶來極大方便。

一、啟動

1、首先確認所被啟動的車輛蓄電池電壓為12V或24V。正、負極不得接反。12V正極連接線連接到標有12V“+”的位置。24V正極連接線連接到標有24V“+”的位置。負極不分12V/24V均連接在標有起動“-”的位置。

2、用連接線將啟動電源和蓄電池正負極對應連接。

3、確認連接無誤：打開保護開關將電流調節旋鈕撥至**檔，開始起動車輛。如起動馬力不足可將電流調節旋鈕順時針方向調節。（也可以將電流調節扭直接調至起動檔，即**大檔）

二、充電

根據電池電壓用連接線接好，確認12V或24V。給12V電池充電將連接線連接在標有12V“+”的位置，給24V電池充電，將連接線接在標有24V“+”的位置。負極均接在標有充電“—”的位置（12V、24V均接在充電“—”的位置）

三、電焊

1、必須將連接線連接在24V位置。正極接在標有24V“+”的位置上，負極接在起動“—”的位置上。

2、調節電流旋鈕至焊接位置，也可根據焊條大小順時針調節電流增大。（也可直接將電流旋鈕調至焊接位置）

技術指標

型號	**大起動電流（A）	充電電流（A）	輸入電壓AC（V）	輸出電壓DC(V)	頻率（Hz）	適用車輛
SDD-500A	300	50	180-240	12、24	50/60	小型車輛啟動
SDD-1500A	1500	50	220-380	12、24	50/60	中、小型車輛啟動
SDD-2500A	2500	50	220-380	12、24	50/60	大、中型車輛啟動

Product Introduction

1、Starting power is necessary tool for vehicle maintenance industry. Its function is battery charging、vehicle starting、and welding etc., especially used in could case. A starting power largely reduces a burden of batteries, prolongs the service life of batteries, and provides a great convenience for consumers.

一、Starting

1、First of all, confirm the started vehicle battery voltage is 12 V or 24V. Positive and negative can not be connected in reverse. 12V anode is connected to the 12V positive position with “+”mark. 24V cathode is connected to 24V negative position with “+”mark. Negative does not distinguish 12V from 24V. Positive and negative are connected to the starting position with “-” mark.

2、With connection lines, the positive and negative poles of the starting power supplies and batteries are connected correspondingly.

3、Carefully confirm connection: open a protection switch, shift the current regulation knob to first gear; Then begin to start a car. If the starting horsepower is insufficient, clockwise adjust the current adjusting knob.

二、Charge

According to battery voltage, connection lines are connected tightly ,and make confirmation of voltage for 12.0 V or 24 V. Charging a battery with 12 V, make connection line to the 12 V position labeled as “+”. Charging a battery for 24 V, set connection line on 24 V position marked as “+”. Cathodes are all connected to charging position labeled as " - " (12V and 24V both are joined to charging " - " position)

三、Welding

1、A connection line must connect to 24V position. Positive electrode joins to the 24V position labeled as " + ", negative electrodes all are joined to the starting position labeled as “－”

2、Regulate a current knob to a welding position, Also can be based on a welding size, increase clockwise current.

(Also possibly and directly regulate a current knob to the welding position)
